Description
B650I + ITX GPU(length limit 235mm) + AK500 Series + PQ-M Series
B760I + RTX 4070/NVIDIA GeForce RTX 4090(length limit 305mm) + AK620 Series + SFX PSU
| Model | R-CH160-WHNGI0-G-1 |
| Dimensions | 336×200×283.5mm |
| Form Factor | Mini Tower |
| Materials | ABS+SPCC+Tempered Glass |
| Mainboard Support | Mini-ITX |
| I/O Ports | USB3.0×2 Audio×1 Gen2 Type-C×1 |
| Side Panel | Tempered Glass |
| Expansion & Drive Bays | |
| Expansion Slots | 3 Slots |
| 3.5 Drive Bays | 1(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) |
| 2.5 Drive Bays | 1(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) |
| Fan Support | |
| Front | 1×120 mm(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) |
| Top | 2×120 mm |
| Rear | 1×120mm |
| Pre-Installed Fans | None |
| Fan RGB Effect | No |
| Radiator Support | |
| Front | N/A |
| Top | N/A |
| Rear | N/A |
| Clearance | |
| CPU Cooler Height Limit | 172mm |
| GPU Size Limit | Length: SFX/SFX-L: 305mm / ATX: 230mm Height: 138mm Width: 65mm (3 Slots) |
| Power Supply Type | ATX PS2(maximum length: 140mm)/ SFX / SFX-L |
| Miscellaneous | |
| Dust Filters | Yes |
| Net Weight | 3.3Kg |
| Gross Weight | 4.0KG |
| Warranty | 3 Year of Brand Warranty |
